ARCALUB-C8-2P

Ilość (szt.)

Dodaj produkt do porównania

Unit system

Technical data

	Piston pump	Functional principle
V_Lub	800 cm³	Lubricant volume
	0,15 cm³	Metering quantity (per outlet and stroke/impulse)
p_op	70 bar	Operating pressure, max.
	≤ NLGI 3 (suitability test required)	Lubricant
n_pb	2	Number of pump bodies
n_out	4	Number of outlets
	≤ 8	Number of lubrication points: direct
	≤ 16	Number of lubrication points: with splitters
	> 16	Number of lubrication points: with progressive distributors
	PA hose	Connection
U_op	DC 24 V	Operating voltage
	M12 x 1, 4 pin	Connection plug for multi-function interface
I_max	≤ 350 mA	Current consumption (DC 24 V)
	microelectronic	Controller (integrated)
	PLC	Controller (extern)
	Integrated, electronic	Monitoring: pressure
	Integrated, reed switch	Monitoring: fill level
	Empty level, back pressure, internal error (PLC)	Error message
	IP65	Protection class
	Aluminium (powder coated), polyamide	Housing material
t_min	-20 °C	Operating temperature, min.
t_max	70 °C	Operating temperature, max.
	vertical	Mounting position
	158 x 273 x 152	Dimensions (mm)
≈m	3 kg	Masa
