ARCALUB-C2-2P-OIL-24VDC

Ilość (szt.)

Dodaj produkt do porównania

Unit system

Technical data

	Piston pump	Functional principle
V_Lub	300 cm³	Lubricant volume
	0,15 cm³	Metering quantity (per outlet and stroke/impulse)
p_op	30 bar	Operating pressure, max.
	Lubricating oil > 68 mm²/s	Lubricant
n_pb	2	Number of pump bodies
n_out	2	Number of outlets
	≤ 2	Number of lubrication points: direct
	≤ 4	Number of lubrication points: with splitters
	> 4	Number of lubrication points: with progressive distributors
	PA hose	Connection
U_op	DC 24 V	Operating voltage
	M12 x 1, 4 pin	Connection plug for multi-function interface
I_max	<= 250 mA	Current consumption (DC 24 V)
	microelectronic	Controller (integrated)
	PLC	Controller (extern)
	Integrated, electronic	Monitoring: pressure
	External (PLC)	Monitoring: fill level
	Empty level, back pressure, internal error (PLC)	Error message
	IP54	Protection class
	Polyamide	Housing material
t_min	-20 °C	Operating temperature, min.
t_max	70 °C	Operating temperature, max.
	vertical	Mounting position
	91 x 223 x 112	Dimensions (mm)
≈m	1 kg	Masa
