GE20-FO-2RS
Spherical plain bearing
High performance Radial spherical plain bearing, requiring maintenance, sliding contact surface: steel/steel, DIN ISO 12240-1, dimension series G, sealedHigh-performance: For highest load rating and lifetime demands
Main Dimensions & Performance Data
| d | 20 mm | Bore diameter bearing |
| D | 42 mm | Outside diameter bearing |
| B | 25 mm | Width Inner ring |
| Cr | 62.800 N | Basic dynamic load rating, radial |
| C0r | 241.000 N | Basic static load rating, radial |
| ≈m | 0,147 kg | Masa |
Mounting dimensions
| r1smin | 0,3 mm | Edge Spacing |
| r2smin | 0,6 mm | Edge Spacing |
| da max | 25,2 mm | Connection measure Inner ring |
| Da min | 33 mm | Housing Connection Diameter |
Dimensions
| C | 16 mm | Width Outer ring |
| dK | 35,5 mm | Ball diameter |
| α | 17 ° | Tilt angle |
| dOT | 0 mm | Bore diameter bearing, upper tolerance |
| dUT | -0,01 mm | Bore diameter bearing, lower tolerance |
| DOT | 0 mm | Outside diameter, upper tolerance |
| DUT | -0,011 mm | Outside diameter, lower tolerance |
| BOT | 0 mm | Width inner ring, upper tolerance |
| BUT | -0,12 mm | Width inner ring, lower tolerance |
| COT | 0 mm | Width outer ring, upper tolerance |
| CUT | -0,24 mm | Width outer ring, lower tolerance |
| Gr | 0,05 - 0,1 | Radial Clearance |
| Grmax | 0,1 mm | Radial clearance, maximum |
| Grmin | 0,05 mm | Radial clearance, minimum |
Temperature range
| Tmin | -30 °C | Operating temperature min. |
| Tmax | 130 °C | Operating temperature max. |
Pliki do pobrania:
Twoja aktualna wersja produktu
| Maintenance | Maintenance required | |
| Material | Steel | Steel |
| Sealing | 2RS | Lip seals on both sides |
| Coating | Durotect M | Inner- and outer ring coated with Durotect M (Manganese Phosphate) |
