TKSD20
Profile rail
Guideways for six-row linear recirculating ball bearing and guideway assembly
Main Dimensions & Performance Data
| h | 18 mm | Height |
| b | 20 mm | Width |
| Tol b | -0,005 mm | Upper tolerance |
| Tol b | -0,035 mm | Lower tolerance |
| ≈m | 2,3 kg/m | Masa |
Mounting dimensions
| K1 MA | 10 Nm | Tightening torque 1 |
| d1 | 5,8 mm | Bore diameter |
Dimensions
| lmax | 3.900 mm | Max length single piece guideway 2 |
| aL min | 20 mm | Distance 3 |
| aL max | 53 mm | Distance 3 |
| aR min | 20 mm | Distance 3 |
| aR max | 53 mm | Distance 3 |
| jL | 60 mm | Increment |
| h1 | 9,6 mm | Length |
| Tol h1 | 0,5 mm | Upper tolerance |
| Tol h1 | -0,5 mm | Lower tolerance |
Additional information
KWSE20... | Usable carriage(s) | |
KUSE20... | Usable linear systems |
Przypisy
1
2
3
Pliki do pobrania:
Twoja aktualna wersja produktu
| Size code | 20 |
Wszystko
Wszystko
2009-09-21 | Anleitung (Montage, Betrieb) | MON 22 | Französisch
Instructions de montage
2008-10-1 | Anleitung (Montage, Betrieb) | MON 22 | Englisch
linear ball bearing and guideway assemblies - KUSE
2021-02-25 | Katalog | PF1 | Englisch
Monorail Guidance Systems
2021-02-25 | Katalog | PF1 | Deutsch
Profilschienenführungen
2008-10-1 | Anleitung (Montage, Betrieb) | MON 22 | Deutsch
Sechsreihige Kugelumlaufeinheiten - KUSE
2009-11-17 | Anleitung (Montage, Betrieb) | MON 22 | Russisch
Линейные направляющие качения с циркуляцией шариков
